MODEL SELECTION CHART

Model No.

Maximum Rated Air Supply (Ps)

Maximum Rated Air Outlet (Po)

Connection Ports

Static Outlet
Stall Pressure

Actual Area Ratio

Displacement Per Stroke
(in3 per cycle)

Air Drive

Air Inlet

Air Outlet

AB-2

150 psig

300 psig

1/4" NPT

1/4" NPT

2 Pa

2:1

2.9

10.3 bar

21 bar

AB-4

150 psig

600 psig

1/4" NPT

1/4" NPT

4 Pa

4:1

1.4

10.3 bar

41 bar

AB-7

150 psig

700 psig

1/4" NPT

1/4" NPT

7 Pa

7:1

.7

10.3 bar

48 bar

M202 - Remote Pilot:This option  provides a 1/8 NPT female port for remotely controlling the start/stop of the  pump by connecting an external air signal to actuate the air cycling valve.
